Switch-planet-16-cong-10-100-1000 - gs-4210-16t2s
- Đây là dòng sản phẩm Switch Planet 16 cổng 10/00/1000 với đặc điểm nổi bật là có 2 cổng module quang SFP tốc độ 10/100/1000 sử dụng cho cáp quang multimode với khoảng cách 550m và cáp quang singlemode lên đến 120km
- 16 cổng RJ45 10/100/1000BASE-T + 2 slot 100/1000BASE-X SFP. Các tính chất Store-and-Forward mode với các tốc độ dây và forwarding. Hỗ trợ 8K cho các địa chỉ MAC. Hỗ trợ 9K cho gói Jumbo. Hỗ trợ chức năng Auto-MDI/MDI-X. Hỗ trợ giao thức CSMA/CD. Thiết kế theo chuẩn A: FCC, CE.
Technical specifications
- Physical Port
- 16 port 10/100/1000BASE-T Gigabit RJ45 copper.
- 2 100/1000BASE-X mini-GBIC/SFP slots.
- RJ45 console interface for switch basic management and setup.
- Reset button for system factory default.
- Switching
- Hardware based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode,
- flow control and auto-negotiation and auto MDI/MDI-X
- Features Store-and-Forward mode with wire-speed filtering and forwarding rates
- IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
- 9K Jumbo frame
- Automatic address learning and address aging
- Supports CSMA/CD protocol
- Layer 2 Features
- Supports VLAN
- IEEE 802.1Q tagged VLAN
- - Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
- - Protocol VLAN
- - Voice VLAN
- - Private VLAN (Protected port)
- - Management VLAN
- - GVRP
- - Supports Spanning Tree Protocol
- - STP (Spanning Tree Protocol).
- - RSTP (Rapid Spanning Tree Protocol).
- - MSTP (Multiple Spanning Tree Protocol).
- - STP BPDU Guard, BPDU Filtering and BPDU Forwarding.
- - Supports Link Aggregation
- - IEEE 802.3ad Link Aggregation Control Protocol (LACP).
- - Cisco ether-channel (Static Trunk).
- - Maximum 8 trunk groups, up to 8 ports per trunk group.
- - Provides port mirror (many-to-1).
- - Loop protection to avoid broadcast loops.
Quality of Service Switch Planet 16 cổng GS-4210-16T2S + SFP
- - Ingress / Egress Rate Limit per port bandwidth control.
- - Traffic classification: IEEE 802.1p CoS; DSCP / IP Precedence of IPv4 / IPv6 packets.
- - Strict priority and Weighted Round Robin (WRR) CoS policies.
- Multicast
- - Supports IPv4 IGMP snooping v2 and v3.
- - Supports IPv6 MLD snooping v1, v2.
- - IGMP querier mode support.
- - IGMP snooping port filtering.
- - MLD snooping port filtering.
- Security
- - Storm Control support: Broadcast/ Unknown-Unicast/ Unknown-Multicast.
- - Authentication
- - IEEE 802.1X port-based network access authentication.
- - Built-in RADIUS client to co-operate with the RADIUS servers.
- - DHCP Option 82.
- - RADIUS / TACACS+ authentication.
- - Access Control List
- - IPv4 / IPv6 IP-based ACL.
- - IPv4 / IPv6 IP-based ACE.
- - MAC-based ACL.
- - MAC-based ACE.
- - MAC Security
- - Static MAC.
- - MAC Filtering.
- - Port security for source MAC address entries filtering.
- - DHCP snooping to filter distrusted DHCP messages.
- - Dynamic ARP inspection discards ARP packets with invalid MAC address to IP address binding.
- - IP source guard prevents IP spoofing attacks.
- - DoS attack prevention.
- Management
- - IPv4 and IPv6 dual stack management.
- - Switch Management Interface.
- - Local Command Line Interface.
- - IPv4 / IPv6 Web switch management.
- - Telnet Command Line Interface.
- - SNMP v1, v2c and v3.
- - HTTPs secure access.
- - Built-in Trivial File Transfer Protocol (TFTP) client.
- - Static and DHCP for IP address assignment.
- - System Maintenance
- - SNTP Network Time Protocol.
- - Cable diagnostics.
- - Link Layer Discovery Protocol (LLDP) Protocol and LLDP-MED.
- - SNMP trap for interface Link Up and Link Down notification.
- - Event message logging to remote Syslog server.
- - Four RMON groups (history, statistics, alarms and events).
- - PLANET Smart Discovery Utility.
